Jetway HBJC377F631-4200R (Intel Apollo Lake)

Jetway HBJC377F631-4200R (Intel Apollo Lake)
  • Realtek LAN

  • Intel® Apollo lake Processor (TDP 10W)
  • Support 1 * SO-DIMM DDR3L , up to 8GB memory
  • 2 * USB2.0, 4 * USB3.0, 2 * DP, 2 * RJ45, 1 * SD, 1 * RS232 (RJ45 type)
  • DC-12V_60W FSP Adapter


Share

419.00 EUR
incl. 19% VAT, plus shipping
Available in 3 weeks
Add to cart
MB Model – JNF631-3350 / 3.5” SBC
– JNF631-4200 / 3.5” SBC
Part No. – HBJC377F631-3550B (non-WIFI) / HBJC377F631W3550B (WIFI)
– HBJC377F631-4200B (non-WIFI) / HBJC377F631W4200B (WIFI)
CPU/Chipset – Intel® Apollo lake Processor N Series (TDP 10W)
Memory – 1 * SO-DIMM slots DDR3L-1600MHz , up to 8GB
Storage – 1 * 2.5” SATA3 6Gb/s internal drive bay (Max Height 9.5 mm)
– 1 * M.2 SSD Device (M Key-2242)
– 1 * Micro SD card slot
Network – 2 * Realtek GbE
Expansion – 1 * full-size Mini-PCIe slot (for WiFi expansion)
Rear Panel I/O – 4 * USB 3.0
– 2 * DP (Max. resolution:4096 x 2160@60Hz)
– 2 * RJ45
– 1 * DC-In jack
– 1 * RS232 (RJ45 type)
– 1 * Micro SD
– 1 * Audio (Line out + Mic)
Front Panel I/O – 1 * Power button , 1 * Reset button
– 1 * Power LED , 1 * HDD LED
– 2 * USB 2.0 ports
– 1 * Line-out
– 2 * COM
Power Source – FSP DC Adapter / AC 90~240V input / DC12V-5A-60W / LV6
Compliance – CE, FCC, LVD, RoHS
Safety – Vibration test: N.C
– Shock test: N.C
Temperature – Operating Temperature: 0 ~ 50° C
– Storage Temperature: -10 ~ 70° C
Dimensions – 185 (W) x 142 (D) x 48 (H) mm
Packing – Net Weight: 1.4KG
– Gross Weight: 2.4KG
– Color Box dimension: 250 (W) * 118 (D) * 295 (H) mm
OS Support – Windows 7, Windows 8.1, Windows 10, Linux
Warranty – 2 Year limited warranty
Data sheet Download (PDF)
Data sheet Print view
Jetway Catalog (Rackmount) Download (PDF)
Jetway Catalog (Barebones) Download (PDF)
